Complete technical data, battery variants, charging details, and range table from the official sheet.
Book Test Ride
| Parameter | 40AH | 45AH | 50AH | 55AH | 60AH |
|---|---|---|---|---|---|
| Battery voltage | 72V | 72V | 72V | 72V | 72V |
| Maximum Power* | 2.5 Kw | 2.5 Kw | 2.5 Kw | 2.5 Kw | 2.5 Kw |
| Maximum torque* | 20 Nm | 20 Nm | 20 Nm | 20 Nm | 20 Nm |
| EV battery type | |||||
| Fixing type | Fixed | Fixed | Fixed | Fixed | Fixed |
| Battery capacity* | 40 Ah, 3.072 kWh | 45 Ah, 3.456kWh | 50 Ah, 3.84kWh | 55 Ah, 4.224kWh | 60 Ah, 4.608kWh |
| Range (As per AIS 040) | 90 km - 110 Km | 100 km - 120 Km | 110 km -130Km | 120 km -140Km | 130 km - 150 Km |
| Energy consumption (As per AIS 039) | 25 Wh/km | 25 Wh/km | 25 Wh/km | 25 Wh/km | 25 Wh/km |
| Charger type | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz |
| Charging time (portable charger)* | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) |
| Charging time (fast charger)* | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins |
| Frame type | Alloy | Alloy | Alloy | Alloy | Alloy |
| Overall Length | 1840 mm | 1840 mm | 1840 mm | 1840 mm | 1840 mm |
| Overall Width | 725 mm | 725 mm | 725 mm | 725 mm | 725 mm |
| Overall Height | 1245 mm | 1245 mm | 1245 mm | 1245 mm | 1245 mm |
| Wheel Base | 1365 mm | 1365 mm | 1365 mm | 1365 mm | 1365 mm |
| Ground Clearance | 170 mm | 170 mm | 170 mm | 170 mm | 170 mm |
| Seat Height | 815 mm | 815 mm | 815 mm | 815 mm | 815 mm |
| Curb mass | 74kg | 74kg | 74kg | 74kg | 74kg |
| Wheels | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum |
| Front | Disc | Disc | Disc | Disc | Disc |
| Rear | Disc | Disc | Disc | Disc | Disc |
| Front | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped |
| Rear | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped |
| Front | 90/90-12 tubeless | 90/90-12 tubeless | 90/90-12 tubeless | 90/90-12 tubeless | 90/90-12 tubeless |
| Rear | 90/90-12 tubeless | 90/90-12 tubeless | 90/90-12 tubeless | 90/90-12 tubeless | 90/90-12 tubeless |
| Rake / Trail | 28.2° / 94 mm | 28.2° / 94 mm | 28.2° / 94 mm | 28.2° / 94 mm | 28.2° / 94 mm |
| Headlight | LED | LED | LED | LED | LED |
| Tail Light | LED | LED | LED | LED | LED |
| DRL | LED | LED | LED | LED | LED |
| BATTERY | 72V-40AH lithium battery | 72V-45AH lithium battery | 72V-50AH lithium battery | 72V-55AH lithium battery | 72V-60AH lithium battery |
