ZANUR
Complete technical data, battery variants, charging details, and range table from the official sheet.
Book Test Ride
| Parameter | 40AH | 45AH | 50AH | 55AH | 60AH |
|---|---|---|---|---|---|
| Battery voltage | 72V | 72V | 72V | 72V | 72V |
| Maximum Power* | 1.2 Kw | 1.2 Kw | 1.2 Kw | 1.2 Kw | 1.2 Kw |
| Maximum torque* | 15 Nm | 15 Nm | 15 Nm | 15 Nm | 15 Nm |
| EV battery type | |||||
| Fixing type | Fixed | Fixed | Fixed | Fixed | Fixed |
| Battery capacity* | 40AH, 3.072 kWh | 45AH, 3.456 kWh | 50AH, 3.84 kWh | 55AH, 4.224 kWh | 60AH, 4.608 kWh |
| Range (As per AIS 040) | 100 km - 120 Km | 110 km - 130 Km | 120 km -140Km | 130 km -150Km | 140 km - 160 Km |
| Energy consumption (As per AIS 039) | 19.2 Wh/km | 19.2 Wh/km | 19.2 Wh/km | 19.2 Wh/km | 19.2 Wh/km |
| Charger type | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz |
| Charging time (portable charger)* | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) |
| Charging time (fast charger)* | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins |
| Frame type | Alloy | Alloy | Alloy | Alloy | Alloy |
| Overall Length | 1760 mm | 1760 mm | 1760 mm | 1760 mm | 1760 mm |
| Overall Width | 680 mm | 680 mm | 680 mm | 680 mm | 680 mm |
| Overall Height | 1120 mm | 1120 mm | 1120 mm | 1120 mm | 1120 mm |
| Wheel Base | 1265 mm | 1265 mm | 1265 mm | 1265 mm | 1265 mm |
| Ground Clearance | 158 mm | 158 mm | 158 mm | 158 mm | 158 mm |
| Seat Height | 755 mm | 755 mm | 755 mm | 755 mm | 755 mm |
| Curb mass | 58 kg | 58 kg | 58 kg | 58 kg | 58 kg |
| Wheels | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum |
| Front | Disc | Disc | Disc | Disc | Disc |
| Rear | Disc | Disc | Disc | Disc | Disc |
| Front | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped |
| Rear | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped |
| Front | 3.0-10 tubeless | 3.0-10 tubeless | 3.0-10 tubeless | 3.0-10 tubeless | 3.0-10 tubeless |
| Rear | 3.0-10 tubeless | 3.0-10 tubeless | 3.0-10 tubeless | 3.0-10 tubeless | 3.0-10 tubeless |
| Rake / Trail | 28.3° / 78 mm | 28.3° / 78 mm | 28.3° / 78 mm | 28.3° / 78 mm | 28.3° / 78 mm |
| Headlight | LED | LED | LED | LED | LED |
| Tail Light | LED | LED | LED | LED | LED |
| DRL | LED | LED | LED | LED | LED |
| BATTERY | 72V40AH lithium battery | 72V45AH lithium battery | 72V50AH lithium battery | 72V55AH lithium battery | 72V60AH lithium battery |
