Complete technical data, battery variants, charging details, and range table from the official sheet.
Book Test Ride
| Parameter | 40AH | 45AH | 50AH | 55AH | 60AH |
|---|---|---|---|---|---|
| EV Drivetrain | |||||
| Battery voltage | 72V | 72V | 72V | 72V | 72V |
| Maximum Power* | 3.0 Kw | 3.0 Kw | 3.0 Kw | 3.0 Kw | 3.0 Kw |
| Maximum torque* | 140 Nm | 140 Nm | 140 Nm | 140 Nm | 140 Nm |
| EV battery type | |||||
| Fixing type | Fixed | Fixed | Fixed | Fixed | Fixed |
| Battery capacity* | 40 Ah, 2.88 kWh | 45 Ah, 3.24 kWh | 50 Ah, 3.60 kWh | 55 Ah, 3.96 kWh | 60 Ah, 4.32 kWh |
| Range (As per AIS 040) | 70 km - 90 Km | 80 km - 100 Km | 100 km - 120 Km | 110 km - 130 Km | 120 km - 140 Km |
| Energy consumption (As per AIS 039) | 48 Wh/km | 48 Wh/km | 48 Wh/km | 48 Wh/km | 48 Wh/km |
| Charger type | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz | Off-board type. Single-phase\n\nAC200-240V 50/60Hz |
| Charging time (portable charger)* | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) | (0-80%) – 4 hrs 30 mins (Ambient Temp. 25deg) |
| Charging time (fast charger)* | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins | (0-80%) – 1 hrs 12 mins |
| Frame type | Alloy | Alloy | Alloy | Alloy | Alloy |
| DIMENSIONS & WEIGHT | DIMENSIONS & WEIGHT | DIMENSIONS & WEIGHT | - | - | - |
| Overall Length | 1920 mm | 1920 mm | 1920 mm | 1920 mm | 1920 mm |
| Overall Width | 690 mm | 690 mm | 690 mm | 690 mm | 690 mm |
| Overall Height | 1230 mm | 1230 mm | 1230 mm | 1230 mm | 1230 mm |
| Wheel Base | 1380 mm | 1380 mm | 1380 mm | 1380 mm | 1380 mm |
| Ground Clearance | 180 mm | 180 mm | 180 mm | 180 mm | 180 mm |
| Seat Height | 805 mm | 805 mm | 805 mm | 805 mm | 805 mm |
| Curb mass | 84 kg | 84 kg | 84 kg | 84 kg | 84 kg |
| Wheels | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum |
| BRAKES | BRAKES | BRAKES | - | - | - |
| Front | Disc | Disc | Disc | Disc | Disc |
| Rear | Disc | Disc | Disc | Disc | Disc |
| SUSPENSION | SUSPENSION | SUSPENSION | - | - | - |
| Front | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped | Telescopic, Coil Spring ,Oil Damped |
| Rear | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped | Swingarm type, coil spring, oil damped |
| TYRES SIZE | TYRES SIZE | TYRES SIZE | - | - | - |
| Front | 90/90-17 tubeless | 90/90-17 tubeless | 90/90-17 tubeless | 90/90-17 tubeless | 90/90-17 tubeless |
| Rear | 90/90-17 tubeless | 90/90-17 tubeless | 90/90-17 tubeless | 90/90-17 tubeless | 90/90-17 tubeless |
| Rake / Trail | 26° / 89 mm | 26° / 89 mm | 26° / 89 mm | 26° / 89 mm | 26° / 89 mm |
| ELECTRICAL | ELECTRICAL | ELECTRICAL | - | - | - |
| Headlight | LED | LED | LED | LED | LED |
| Tail Light | LED | LED | LED | LED | LED |
| DRL | LED | LED | LED | LED | LED |
| BATTERY | 72V40AH lithium battery | 72V45AH lithium battery | 72V50AH lithium battery | 72V55AH lithium battery | 72V60AH lithium battery |
